1230 x 830 x 980

System Quad SmartFix® SuperQuad SmartFix®

The KTP SuperQuad SmartFix® container is the perfect replacement for the conventional pallet cage. Developed for use in high-bay racking, this load carrier is also ideal for heavy packaged goods. It is fully compatible and stackable with the pallet cage and existing inlays can simply continue to be used.
Download datasheet

All product benefits at a glance

  • SuperQuad SmartFix® as a pallet cage replacement
  • Extremely stable pallet structure
  • High payloads possible
  • One-piece with super-fast folding technology
  • Sliding lid
  • Extremely easy handling

Highlights

All product benefits at a glance

1
Secure lid guide
  • Recessed guide rails simplify handling - resulting in clean guidance when opening and closing the lid
2
Closed pallet deck
  • No floor insert required
  • No soiling
3
Automatic locking
  • No extra handles necessary
  • Snap-in principle for stable fixation
4
Safe empties unit
  • Protection of the inner ring
  • No container damage due to slipping
  • Safe and stable stacking of containers in full and empty containers
5
Fixed connection
  • No more individual parts - lid, ring and pallet form a firmly connected unit
  • No loss of container parts

Technical data

  • External dimensions
    1230 x 830 x 980mm
  • Internal dimensions
    1195 x 795 x 780mm
  • Volume
    741l
  • Tare weight
    45kg
  • Empties height
    220
  • Folding system
    Sandwichfaltung
  • High rack (without base)

Loads

  • Payload (max.)
    500 kg
  • Stacking load (max.)
    830kg
  • Stacking factor (with max. payload and stacking load)
    1 + 2

Logistics and transport

  • Return rate
    4.3
  • Volume reduction
    77%
77% Volume reduction

Capacity utilisation in mega-trailer
(13,6 x 2,48 x 3,0 m)

Full: 96

Empty: 416

Storage positions: 32

Composition

Three parts to the perfect transport container

Three become one – the patented and multi-award-winning SmartFix® container equipment turns a three-part container into a single unit. The pallet, ring, and lid are firmly connected to each other. Setting up a container has never been so quick and easy. The KTP Sandwich guarantees durability, protection, volume reduction in empties, maximum ergonomics, and easy handling.

Pallet

  • Material
    PE

Equipment*

  • Closed pallet deck
  • 4 feet
  • Water drainage holes
  • Retractable on 4 sides

Sleeve

  • Material
    PP
  • Grammage/Strength
    3000 g/m²

Equipment*

  • M-folding
  • 2 document pockets A5
  • 4 recessed recesses for pallet

Lid

  • Material
    PE

Equipment*

  • 3 handles (2x black 1x blue)
  • Suspension hook

*optional; further options available

More container options such as additional loading flaps, individual printing, tracking systems and customised inner packaging solutions are available on request – just contact us.
