1230 x 830 x 980

System Quad-H Standard Uno

The KTP Uno container is the perfect replacement for the conventional pallet cage. Developed for use in high-bay racking, this load carrier is also ideal for heavy packaged goods. It is fully compatible and stackable with the pallet cage and existing inlays can simply be reused.

All product benefits at a glance

  • Quad Uno as a lattice box replacement
  • Extremely stable pallet structure
  • High payloads possible
  • Intuitive, fast, ergonomic handling
  • Protection against water and dirt
  • No manual locking required

Highlights

All product benefits at a glance

1
Attachable lid
  • Space saving on site
  • Plus in ergonomics and handling
2
Sturdy pallet with runners
  • Fixed, one-piece connection of base and pallet
  • High stability - suitable for high-bay racking and roller conveyors
3
Closed pallet deck
  • No floor insert required
  • No soiling
4
Automatic locking
  • No extra handles necessary
  • Snap-in principle for stable fixation
5
Safe empties unit
  • Protection of the inner ring
  • No container damage due to slipping
  • Safe and stable stacking of containers for full and empty containers

Technical data

  • External dimensions
    1230 x 830 x 980mm
  • Internal dimensions
    1195 x 795 x 780mm
  • Volume
    741l
  • Tare weight
    40kg
  • Empties height
    215
  • Folding system
    Sandwichfaltung
  • High rack (without base)

Loads

  • Payload (max.)
    350 kg
  • Stacking load (max.)
    830kg
  • Stacking factor (with max. payload and stacking load)
    1 + 3

Logistics and transport

  • Return rate
    4.3
  • Volume reduction
    77%
77% Volume reduction

Capacity utilisation in mega-trailer
(13,6 x 2,48 x 3,0 m)

Full: 96

Empty: 416

Storage positions: 32

Composition

Three parts to the perfect transport container

KTP offers you a “genuine” three-piece container* which, thanks to its clever sandwich system folding, remains a secure and, above all, complete packaging unit at all times – whether full or empty. The KTP sandwich guarantees durability, protection, volume reduction in empty containers, maximum ergonomics, and easy handling.

Pallet

  • Material
    PE

Equipment*

  • Closed pallet deck
  • 4 feet
  • Water drainage holes
  • Retractable on 4 sides

Sleeve

  • Material
    PP
  • Grammage/Strength
    3000 g/m²

Equipment*

  • M-folding
  • 2 document pockets A5
  • 4 recessed recesses for pallet

Lid

  • Material
    PE

Equipment*

  • 2 handles (black)
  • Suspension hook

*optional; further options available

More container options such as additional loading flaps, individual printing, tracking systems and customised inner packaging solutions are available on request – just contact us.
